Kafka Certification Tips for Developers

Kafka Certification Tips

If you are considering Kafka Certification, this page describes what I did to pass the Confluent Certified Developer for Apache Kafka Certification exam.  Good luck and hopefully this page is helpful for you!

There are many reasons why you may wish to become Kafka certified.

Achieving Kafka Certification might be a way to distinguish yourself in your current role.  Or, you may wish to transition to a new role which includes a higher bill rate for Kafka contract work.  Or, you may just like the pressure of testing yourself and your Kafka developer chops.  Whatever your reasons, it doesn’t matter here folks.  We are all equal under the stars in the sky.  Well, I’m not exactly sure that’s true about all being equal, but it sounds pretty good, right?  Sometimes, when you are Kafka certified, you need to sound good when you are speaking and writing.  Pfft…lol, anyhow, let’s get serious.

I achieved the Kafka Developer certification through hard work.  I had a couple of years of Kafka experience, but this experience wasn’t ever really solely focused on Kafka.  Kafka was just a component in the overall stack I needed and/or wanted to utilize.  It was never 100% devoted to Kafka though. Along the way, I wrote some Kafka tutorial blog posts here to help engrain some of my Kafka learnings.

My point is I had some Kafka experience.  And if I’m being honest, I had misconceptions about what Kafka is and is not at times.  If I’m being entirely honest, I still do sometimes.  You see, I’m honest.

Here’s a link to my certification

Kafka Certification
Kafka Certification

With my previously described experience with Kafka in mind, I took the following steps to pass the certification test on my first try.  Consider these my personal Kafka Certification tips and FAQ.

What is Kafka Certification?

Kafka Certification is a program through Confluent and at the time of this writing, there are two available certifications.  The Confluent Certified Developer for Apache Kafka (CCDAK) and the Confluent Certified Operator for Apache Kafka (CCOAK).  To become certified, you must take a remotely proctored exam from your computer.  Does anyone else think “remotely proctored” sounds a bit…. well, odd.

Are there multiple types of Kafka Certification?

Yes. This post, certification suggestions, and descriptions focus on the Kafka Developer certification.

What should you study to become Apache Kafka Certified?

Well, first off, you should be prepared for more than just Kafka, the distributed commit log, Consumers and Producers.  This is what most people think of when they hear Kafka.  The exam will also test your knowledge in areas such as Kafka Connect, Kafka Streams, KSQL and the Schema Registry.  I cover this in more detail in the next questions.

What is the percentage breakout of questions on Kafka vs. Kafka Streams, etc?

According to the developer’s certification guide from Confluent (at the time of this writing), we are given the following guidance on the breakout.

Application Design 40% which includes command-line tools, configuration, metrics, architecture, and design

Development 30% which is focused on Java Consumer and Producer APIs as well as the REST API

Deployment/Testing/Monitoring 30% includes tuning for latency/throughput, Kafka Streams, KSQL and troubleshooting

This percentage breakout is taken directly from the Confluent Certification Guide.  There is a link to this Guide in the Resources section below.

Are there any Kafka Certification practice tests?

Yes and I purchased a Kafka Certification practice exam course on Udemy and it helped.  It includes 3 sets of practice tests.

How did you prepare for the exam?

I started by reading documentation and performing some hands-on examples from both the Apache Kafka and Confluent documentation.  I read these Kafka docs pretty quickly at first because I wanted to obtain the big picture view of my skills.

Next, I took the first set of practice questions from the practice tests course I purchased. The results of this first practice test showed where I was strong and where I was weak.

Next, I went back to both the Apache Kafka and Confluent documentation and read more carefully in the areas where I needed improvement.

Afterward, I took the 2nd practice test with higher expectations this time.  Again, the results provided an updated assessment of my current Kafka skills and showed me my weaknesses.  This time, I studied where I was weak again.  But, I also spent 10-20% of the time in areas where I already felt confident.

By now, I imagine you can guess what I did next.  I took the third series in the practice exam set.

At this point, I was feeling pretty confident, so I scheduled my test and began studying the documentation again for 30min to 1 hour a day for each day before the exam.

Please describe the “proctor” experience?

Well, let me tell you they are not kidding about wanting to view the area where you take the test.  I had to spin my webcam 360 degrees.  The proctor asked questions about my dual monitor setup and was quite concerned.  I had to disconnect my second monitor and external camera.

Any Kafka Developer Certification sample questions you can share?

Well, the Confluent Certification guide contains a few sample questions, but from my personal experience, I’d buy the recommended practice exam questions I mentioned above and below.

Anything you didn’t do to prepare, but considered doing?

I kept it simple.  I didn’t buy any courses from Udemy or Pluralsight, but I admit I was tempted to buy.  Instead, I just purchased the practice exams and studied the Apache Kafka and Confluent documentation.  I was tempted to, but the documentation is good and there are plenty of examples on the Internet.  According to Steven Pressfield, I just needed to “do the work”.

Final Thoughts or any other helpful resources



Featured image https://pixabay.com/users/insspirito-1851261/

Kafka Test Data Generation Examples

Kafka Test Data Generation

After you start working with Kafka, you will soon find yourself asking the question, “how can I generate test data into my Kafka cluster?”  Well, I’m here to show you have many options for generating test data in Kafka.  In this post and demonstration video, we’ll cover a few of the ways you can generate test data into your Kafka cluster.

Now, before we begin, let’s cover a possible edge case.  If you are wondering about test data in Kafka Streams applications, you might find my previous post on testing Kafka Streams helpful. Well, also, I might find it helpful if you read it and comment on it too.

With that out of the way, let’s go through a few of your options.  I’ll cover ways to generate test data in Kafka from both Apache Kafka and Confluent Platform.

Kafka Test Data Screencast (AKA: Big Time TV Show)

Check out the screencast below to see a demo of examples using kafkacat, Kafka Connectors Datagen and Voluble and finally, ksql-datagen

Part 1 with Kafkacat

Our first example utilizes the kafkacat which is freely available at https://github.com/edenhill/kafkacat/

Here are the steps (more or less) in the above screencast

  1. Start Zookeeper and Kafka on localhost
  2. kafkacatis installed and in my path
  3. cat /var/log/system.log | kafkacat -b localhost:9092 -t syslog
  4. kafkacat -b localhost:9092 -t syslog -J
  5. curl -s “http://api.openweathermap.org/data/2.5/weather?q=Minneapolis,USA&APPID=my-key-get-your-own” |\
    kafkacat -b localhost:9092 -t minneapolis_weather -P
  6. kafkacat -b localhost:9092 -t minneapolis_weather
  7. Show other fun, good time resources such as Mockeroo and JSON-server

Test Data with Apache Kafka Connect Options

There are a couple of available Kafka Connect source connectors to assist in generating test data into Kafka.   There is the Kafka Connect Datagen connector which has been around for a while.  The Datagen connector includes two quickstart schemas to ahh, well, you know, get you started quickly.  See the Reference section below for the link.

In the screencast, I showed how both connectors are already installed.

Next, run some commands such as

  1. confluent local config datagen-pageviews — -d ./share/confluent-hub-components/confluentinc-kafka-connect-datagen/etc/connector_pageviews.config (your path might be different)
  2. kafkacat -b localhost:9092 -t pageviews

Next, we switched to another option for Kafka Connect based Kafka mock (or stub) data generation is a connector called Voluble.  I like how it integrates the Java Faker project which provides support for creating cross-topic relationships such as seen the examples

'genkp.users.with' = '#{Name.full_name}'
'genvp.users.with' = '#{Name.blood_group}'

'genkp.publications.matching' = 'users.key'
'genv.publications.title.with' = '#{Book.title}'

See how the users.keyis referenced in the above example.  Anyhow, much more documentation available from Github repo in the link below.

Steps with Voluble

  1. Listed topics kafka-topics – list – bootstrap-server localhost:9092
  2. Then, I loaded using a sample properties file found in my Github repo.  See the Resources below.
  3. confluent local load voluble-source – -d voluble-source.properties (bonus points and a chance to join me on a future Big Time TV Show if you post how to load it in vanilla Kafka in the comments below.  )
  4. kafka-topics – list – bootstrap-server localhost:9092
  5. kafkacat -b localhost:9092 -t owners

Kafka Test Data in Confluent Platform

If you are a user of the Confluent Platform, you have an easy button available from the CLI with ksql-datagentool.  It has a couple of quickstart schemas to get you rolling quickly as shown in the following screencast

Quickly, let’s run through the following commands

  1. ksql-datagen quickstart=orders format=avro topic=orders maxInterval=100
  2. confluent local consume orders – – value-format avro – from-beginning
  3. kafkacat -b localhost:9092 -t orders -s avro -r http://localhost:8081

Resources and Helpful References



Featured image credit https://pixabay.com/photos/still-life-bottles-color-838387/

Kafka Producer

Kafka Producer Example

Kafka Producers are one of the options to publish data events (messages) to Kafka topics.  Kafka Producers are custom coded in a variety of languages through the use of Kafka client libraries.  The Kafka Producer API allows messages to be sent to Kafka topics asynchronously, so they are built for speed, but also Kafka Producers have the ability to process receipt acknowledgments from the Kafka cluster, so they can be as safe as you desire as well.

For a refresher on this, please see What is Kafka?

Kafka Producer Objective

In this Kafka Producer tutorial, let’s examine a Kafka Producer example and highlight some of the key features and customization options.  It assumes the reader is already familiar with Kafka architectural components such as Producers, Consumers, and Topics.  For a list of other Kafka resources, see Kafka Tutorials page.

On the surface, the idea behind a Kafka Producer is simple.  Send messages to topics.  In Kafka Producer example in this tutorial, we’re going with an easy example of sending to a topic with a single partition.  However, in larger environments, the dynamics of optimized Kafka Producer performance changes.  For example, in production deployments, we will want to experiment and test different batch sizes, compression and possibly even custom partitioners.  Factors which will affect these tests and experiments include the configured replication factor of the topic(s) in question.   We’ll touch upon some of these options and design decisions throughout this tutorial.

Kafka Producer Example Screencast

Before we begin analysis of the Kafka Producer example client source code, let’s show how to run the example in the following screencast

Outside of running and debugging in IntelliJ, we also use the `kafka-console-consumer` command-line tool to inspect messages being sent to the topic in a few different ways including

`./bin/kafka-console-consumer – bootstrap-server localhost:9092 – topic example-topic`

and

`./bin/kafka-console-consumer – bootstrap-server localhost:9092 – topic example-topic – property print.key=true – property key.separator=:: – from-beginning`

Kafka Producer Source Code

Developing Kafka Producers is similar to developing Kafka Consumers by which a Kafka client library is made available to your source code project.   As we saw in the Kafka Consumer tutorial, if you are using a build tool like SBT or Maven, it’s just a matter of adding the library as a dependency, for example

val kafka = "0.10.2.1"
libraryDependencies += "org.apache.kafka" % "kafka-clients" % kafka

Let’s start by looking at some of the option Kafka Producer configuration options that are commented out by default.

p.put(ProducerConfig.ACKS_CONFIG, "all")
p.put(ProducerConfig.RETRIES_CONFIG, 0)
p.put(ProducerConfig.BATCH_SIZE_CONFIG, 16384)
p.put(ProducerConfig.LINGER_MS_CONFIG, 1)
p.put(ProducerConfig.RETRIES_CONFIG, "TODO")
p.put(ProducerConfig.BUFFER_MEMORY_CONFIG, 33554432)

As we saw in the above screencast, these variables are instances of `static final String` and are provided for conveniently setting the underlying configuration key.  For example, `ACKS_CONFIG` default setting in the underlying Java code is:

public static final String ACKS_CONFIG = "acks";

As a Kafka developer, administrator, or architect, you have options on how to design the desired performance characteristics of your Kafka Producer.  These Kafka Producer configuration options are your first stop for tuning for both speed and safety.  (Note: we’re not going to cover all the configuration options; just the ones in this example.)

Kafka Producer `ack` configuration

`ack` specifies the number of replicas which need to respond in order to consider the message as committed.  Recall each topic in a Kafka cluster has a designated leader and possibly a set of replicas among the brokers.  All writes to a particular partition must go the topic partition leader.  Then, replicas fetch from this leader in order to keep in sync.  With the `ack` setting, the partition leader can wait until the configured amount of replicas have synched before sending a committed response back to the Producer.

Kafka Producer `ack` configuration gives the producer developer control over message durability safety at the cost of throughput.

The strongest durability guarantee is setting `acks` to `all` as shown in the commented out code.  With this `ack` setting, it guarantees the partition leader accepted the write request, but also, it was successfully synchronized to all the replicas.  Other options for `ack` includes 0 and 1.  The default setting is 1.

Kafka Producer Batch Size Configuration

Kafka Producers may attempt to collect messages into batches before sending to leaders in an attempt to improve throughput. Use batch.size (or `BATCH_SIZE_CONFIG` as seen in this example.  Remember it’s a convenience mapping) to control the max size in bytes of each message batch.  You can use `linger.ms` to give more time for batches to fill.

You may be wondering, how do batch transmission and topic partitioning co-exist?

Producers maintain buffers (batches) of unsent records for each partition according to the `batch.size` setting. Increasing the value will result in more batching at the cost of requiring more memory.

Kafka Producer Compression

As described in the previous section, if the Kafka Producer is transmitting a batch of messages, is there an option to compress the batch payload?  Yes, with `compression.type` setting.  The default is `none` but may be set to `gzip`, `snappy`, or `lz4`.

Kafka Producer Asynchronous `send`

A few noteworthy items about the two versions of `send` function shown here

       producer.send(new ProducerRecord(topics, s"key ${k}", "oh the value!"))

      // with example callback
      // producer.send(new ProducerRecord(topics,
                                  s"key ${k}",
                                 "oh the value!"),
                                        callback)

First, the obvious and shown in the screencast.  The `send` function can accept a `Callback` argument which will be invoked on message receipt acknowledgment.  This was demonstrated in the screencast.   The callback implementation will receive two arguments to the overridden implementation of `onCompletion`.  `metadata` includes the partition and offset of the sent message.  `exception` includes approximately 10 variations of exceptions which may be sent.

Second, you may remember the internal mechanics of sending messages include leader determination of topic partitions.  Do you remember what this means?  When a Kafka Producer wants to send a message, it needs to determine the leader (a particular node) of the topic partition.  Any Kafka node in the cluster may answer the Producer’s question on which nodes are alive and who the leaders are for particular partitions in a given topic.  Answering these questions allows the Producer to route the message appropriately.

Noteworthy

Starting with Kafka 0.11 the Kafka Producer supports two additional modes beyond `send`.  They include transactional and idempotent producers.  Let me know if we should cover these two additional capabilities in the future?

Kafka Producer Conclusion

In this tutorial, we created and executed a Kafka Producer in Scala.  Did it help?  Or would you prefer a Java example?  Let me know and let me know if you have any questions or suggestions for improvement.  Enjoy yourselves, people.  Try to be good to one another.

Kafka Producer References

Kafka Consumer

Kafka Consumer

In this Kafka Consumer tutorial, we’re going to demonstrate how to develop and run an example of Kafka Consumer, so you can gain the confidence to develop and deploy your own Kafka Consumer applications.  At the end of this Kafka Consumer tutorial, you’ll have both the source code and screencast of how to run and customize the Kafka Consumer example.

Kafka Consumer Background

As a quick background, recall Kafka Consumers are applications which read messages from Kafka topic partitions.  As previously described in Apache Kafka Overview, Kafka Consumers read messages from Kafka topics in sequential order through use of offsets.  Ordering is a key feature of Apache Kafka and it is what differentiates it from more traditional pub/sub messaging systems.

Kafka messages do not need to be a particular format such as JSON or Avro or plain-text.  There is not a required, formal agreement of data format between Kafka Consumers and Kafka Producers.  In these cases, there is an agreement on what Producers and Consumers can expect in data formats for particular topics.  For those looking to implement more rigidity in data formats and schema validation, there is the option to implement the Confluent Schema Registry with the Avro to ensure a data format contract, but we’ll cover that at a later time.

Three key settings for Kafka Consumers related to how they process messages according to offsets are `auto.offset.reset`, `enable.auto.commit` and `auto.commit.interval.ms`.   Let’s explore this a bit now.

Kafka Consumers will commit their current offset location back to Kafka every 5 seconds by default and when `enable.auto.commit` is set to true (again, the default).  You can change the frequency at which the commits happen by changing the `auto.commit.interval.ms` value.  We’ll show examples and explore this further later in the tutorial.

Kafka Consumer Architecture

When considering the mechanics or flow of data from topics to Consumers\, you may wonder if it is a pull or push action?  In other words, do Kafka Consumers pull messages from Kafka Topics or are messages pushed to Kafka Consumers?  The answer is “pull” based mechanics.  Because one the design goals is allowing consumers to read messages at the best rate for themselves, Kafka Consumers are in control of pulling messages.  A push model would take control away from the Kafka Consumer.

On the subject of Kafka Consumer mechanics, you should be aware of the differences between older and newer Kafka Consumer clients.  Older Kafka clients depended on ZooKeeper for Kafka Consumer group management, while new clients use a group protocol built into Kafka itself.  Using this group protocol, one of the brokers is designated as the Consumer group’s coordinator and is responsible for managing both the members of the group as well as their partition assignments.

As noted in the previous paragraph, Kafka Consumers may be deployed and configured as Kafka Consumer Groups which can be utilized to increase throughput.  Although you will see reference to Consumer Group ID settings in the source code below, we will not be covering the concept of grouping Kafka Consumers in any depth within this tutorial.

Kafka Consumer Example

In this Kafka Consumer tutorial, we’re going to demonstrate how to develop and run a Kafka Consumer.  We’ll use Scala in this example, but the concepts hold true regardless of which language you choose to use.   See the link for Kafka Clients in the Reference section below for alternative language options.

Some of the commands used to send test data to the `example-topic` in the screencast included:

`cat words.txt | ./bin/kafka-console-producer – broker-list localhost:9092 – topic example-topic`

`kafka-console-producer – broker-list localhost:9092 – topic example-topic --property parse.key=true --property key.separator=,`

And then we sent keys and values separated by a comma and ended with Ctrl-D

Next, we explored reading a topic from the beginning rather than the latest, so we changed some default properties and the consumer group id.

Kafka Consumer Example Source Code

Let’s examine the Kafka Consumer relevant source code.  To start, notice how we are setting various required properties as shown here

p.put(ConsumerConfig.GROUP_ID_CONFIG, groupId)
p.put(ConsumerConfig.BOOTSTRAP_SERVERS_CONFIG, bootstrapServers)
p.put(ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG, "org.apache.kafka.common.serialization.StringDeserializer")
p.put(ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG, "org.apache.kafka.common.serialization.StringDeserializer")

// if we want to adjust defaults
// p.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG, "earliest") // default is latest
// p.put(ConsumerConfig.ENABLE_AUTO_COMMIT_CONFIG, false) // default 5000 - change how often to commit offsets
// p.put(ConsumerConfig.AUTO_COMMIT_INTERVAL_MS_CONFIG, 10000) // default 5000 - change how often to commit offsets

We discussed and tried experimenting with most of these properties during the screencast.  If you have any questions, check out the screencast first.

Later, we spawn our Kafka Consumer, set the topic to subscribe, and start polling every second

val consumer = new KafkaConsumer[String, String](props)

consumer.subscribe(Collections.singletonList(this.topics))

while (true) {
  val records = consumer.poll(1000).asScala

  for (record <- records) {
    println("Message: (key: " +
      record.key() + ", with value: " + record.value() +
      ") at on partition " + record.partition() + " at offset " + record.offset())
  }

We’re not doing anything interesting with messages other than displaying keys, values and metadata.  What do you notice about the parition and offset values?  Do you see examples of strict ordering in the partition and offset values?

Finally, we should quickly call out the commented out code towards the end of the `main` function

// if you don't want to auto commit offset which is default
// comment out below and adjust properties above
/*
try
  consumer.commitSync
catch {
  case e: CommitFailedException =>
   // possible rollback of processed records
   // which may have failed to be delivered to ultimate destination
}
*/

By default, Kafka will commit it’s current offset back to Kafka every 5 seconds automatically.  But what if processing fails from the time messages were received until the time the offset is committed back?  Is there a chance to lose data?  Is there a chance to duplicate data?  This is covered in much more detail in the Kafka delivery guarantees post, so I recommend you check that out if interested in learning more.

For now, this commented code and properties such as `ENABLE_AUTO_COMMIT_CONFIG` shown above indicate options you have to tune how delivery vs processing guarantees.

Kafka Consumer Conclusion

I hope you enjoyed and learned from this Kafka Consumer tutorial.  Do let me know if you have any questions or suggestions for improvement.  Thanks!  Next up, you may wish to try the Kafka Producer tutorial and example or move back to the list of Kafka Tutorials.

Kafka Consumer References

Kafka Consumer featured image https://pixabay.com/en/alcohol-drink-alkolismus-bottles-64164/

Kafka Consumer Groups by Example

Kafka Consumer Group Example

Kafka Consumer Groups are the way to horizontally scale out event consumption from Kafka topics… with failover resiliency.  “With failover resiliency” you say!?  That sounds interesting.  Well, hold on, let’s leave out the resiliency part for now and just focus on scaling out.  We’ll come back to resiliency later.

When designing for horizontal scale-out, let’s assume you would like more than one Kafka Consumer to read in parallel with another.  Why?  Maybe you are trying to answer the question “How can we consume and process more quickly?”

Now, we’ve covered Kafka Consumers in a previous tutorial, so you may be wondering, how are Kafka Consumer Groups the same or different?   Well, don’t you wonder too long my Internet buddy, because you are about to find out, right here and right now.  Ready!?  Of course, you are ready, because you can read.  Also, if you like videos, there’s an example of Kafka Consumer Groups waiting for you below too.  The video should cover all the things described here.  Are you ready for a good time?  That should be a song.

Anyhow, first some quick history and assumption checking…

Like many things in Kafka’s past, Kafka Consumer Groups use to have a Zookeeper dependency.  But starting in 0.9, the Zookeeper dependency was removed.  So, if you are revisiting Kafka Consumer Groups from previous experience, this may be news to you.  There’s a link in the Reference section below which you might want to check out if you are interested in learning more about the dependency history.

Kafka Topic Fundamentals

First off, in order to understand Kafka Consumer Groups, let’s confirm our understanding of how Kafka topics are constructed.  Recall that Kafka topics consist of one or more partitions.  There is even a configuration setting for the default number of partitions created for each topic in the server.properties files called `num.partitions` which is by default set to 1.  More partitions allow more parallelism.  Or, put another way and as we shall see shortly, allow more than one Consumer to read from the topic.

To see partitions in topics visually, consider the following diagrams.

A Kafka topic with a single partition looks like this

Kafka Consumer Groups Example One Single Partition Topic
Kafka Consumer Groups Example One

A Kafka Topic with four partitions looks like this

Kafka Consumer Groups Example 2 Four Partitions in a Topic
Kafka Consumer Groups Example 2 Four Partitions in a Topic

And note, we are purposely not distinguishing whether or not the topic is being written from a Producer with particular keys.

Kafka Consumer Group Essentials

Now, if we visualize Consumers working independently (without Consumer Groups) compared to working in tandem in a Consumer Group, it can look like the following example diagrams.

Without Consumer Groups

Kafka Consumer Groups Example 3
Kafka Consumer Groups Example 3

With Consumer Groups

Kafka Consumer Groups Example 4
Kafka Consumer Groups Example 4

Rules of the road

So, to recap, it may be helpful to remember the following rules:

  • Each partition in a topic will be consumed by exactly one Consumer in a Consumer Group
  • Now, one Consumer may consume from more than one partition, if there are fewer Consumers in a Consumer Group than there are topic partitions
  • If you like deploying with efficient use of resources (and I highly suspect you do), then the number of consumers in a Consumer Group should equal or less than partitions, but you may also want a standby as described in this post’s accompanying screencast.

A quick comment on that last bullet point – here’s the “resiliency” bit.  Deploying more Consumers than partitions might be redundancy purposes and avoiding a single point of failure; what happens if my one consumer goes down!?  As we’ll see in the screencast, an idle Consumer in a Consumer Group will pick up the processing if another Consumer goes down.

If bullet points are not your thing, then here’s another way to describe the first two bullet points. Let’s say you N number of consumers, well then you should have at least N number of partitions in the topic. Or, put a different way, if the number of consumers is greater than the number of partitions, you may not be getting it because any additional consumers beyond the number of partitions will be sitting there idle.  We show an example of this in the video later.



Kafka Consumer Group Example

Alright, enough is enough, right.  Let’s get to some code.  In the Consumer Group screencast below, call me crazy, but we are going to use code from the previous examples of Kafka Consumer and Kafka Producer.

We are going to configure IntelliJ to allow us to run multiple instances of the Kafka Consumer.  This will allow us to run multiple Kafka Consumers in the Consumer Group and simplify the concepts described here.  I show how to configure this in IntelliJ in the screencast if you are interested.

And again, the source code may be downloaded from https://github.com/tmcgrath/kafka-examples

Kafka Consumer Groups Examples Pictures and Demo

In the following screencast, let’s cover Kafka Consumer Groups with diagrams and then run through a demo.

The link to the Github repo used in the demos is available below.  Here are the bullet points of running the demos yourself

  • Kafka and Zookeeper are running.  Run list topics to show everything running as expected.
  • Create an example topic with 2 partitions with bin/kafka-topics.sh – create – bootstrap-server localhost:9092 – replication-factor 1 – partitions 2 – topic example-topic
  • Run Consumer 1 (show how to run more than one instance in IntelliJ), Run Consumer 2 (after editing) with different group id and show the output.  Run Producer.  Both consume everything and notice how there is no sequential ordering because Consumers are consuming from both partitions.  Ordering is on a per partition basis.
  • What happens if we change these Consumers to be part of the same group?  Stop Consumers and producer, set new Group id, rerun both, which shows round robin results because the key is unique for each message.
  • What happens if we add a third consumer?  Fire up a third consumer and show how it’s idle, kill one consumer and then re-run the producer to show how consumer 3 is now engaged (note: session.timeout.ms and `heartbeat.interval.ms`)
  • Stop all running consumers and producers.  Restart consumers (notice even though earliest it’s reading… this because already read and stored in `__consumer_offsets`, run Producer with key “red” vs “blue” vs. “green” and now highlight how each consumer goes to each partition in order.  Run a few times.  Note: murmur2 hash on key and the run mod 2 (based on the number of partitions.)
  • Repeat the previous step but use a topic with 3 partitions
  • Repeat the previous step but use a new topic with 4 partitions

Why Kafka Consumer Groups?

In distributed computing frameworks, the capability to pool resources to work in collaboration isn’t new anymore, right?  In other words, you may be asking “why Kafka Consumer Groups?”  What makes Kafka Consumer Groups so special?  Good question, thanks for asking.

To me, the first reason is how the pooling of resources is coordinated amongst the “workers”.  I put “workers” in quotes because the naming may be different between frameworks.  But in this case, “workers” is essentially an individual process performing work in conjunction with other processes in a group or pool.  Multiple processes working together to “scale out”.  In Kafka Consumer Groups, this worker is called a Consumer.

The coordination of Consumers in Kafka Consumer Groups does NOT require an external resource manager such as YARN.  The capability is built into Kafka already.   This is an attractive differentiator for horizontal scaling with Kafka Consumer Groups.  Put another way, if you want to scale out with an alternative distributed cluster framework, you’re going to need to run another cluster of some kind and that may add unneeded complexity.

Now, another reason to invest in understanding Kafka Consumer Groups is if you are using other components in the Kafka ecosystem such as Kafka Connect or Kafka Streams.  Both Kafka Connect and Kafka Streams utilize Kafka Consumer Groups behind the scenes, but we’ll save that for another time.  Or if you have any specific questions or comments, let me know in the comments.

References

Kafka examples source code used in this post

What is a Kafka Consumer?

Kafka Consumer documentation

Introducing the Kafka Consumer: Getting Started with the New Apache Kafka 0.9 Consumer Client



Credits

Kafka Consumer Groups Post image by かねのり 三浦
